MACHINE FEATURES:

SAFETY GUARD

2-piece cast aluminum guard system for best operator's safety. The link operated forward section provides for maximum operator's safety and allows easy and quick saw blade replacement.

DRIVE GEARS

Extremely robust worm & wheel drive with hardened and ground worm shaft. Special bronze worm wheel and a sawblade drive shaft of Ø 70 mm, running in an oil bath. Elastic coupling between motor and drive gears.

AUTOMATIC DOWNFEED SYSTEM

Standard with reliable DRUMAG feeder HPE-11: Quick motion from rest position to the adjustable material level and infinitely adjustable power downfeed motion, with adjustable return point and quick return motion into the upper rest position. This version allows the feeding of the material over the vise into the cutting area, but requires two-hands safety start system.

PIVOT SHAFT

Double joke pivot system with hardened and ground shaft, adjustable on both sides. Low pivot point for extremely little vibration.

MACHINE TABLE

Large, plain table allows individual positioning if the two vise units. Mitering table for horizontal mitering of the saw head within 45° to both sides. Movable rear jaws allow a small cutting slot for easy and accurate straight and mitering cuts through thin-walled material.

SAW BLADE LUBRICATION SYSTEMS

Water coolant system with diaphragm pump, stop cock and large containers for coolant fluid and swarf chips. Plus an additional low-consumption oil spray mist system with precision dispenser from UNIST Inc., USA, recommended for cutting thinner tubes, sections and rectangular profiles.
AIR VISE A strong double-grip air vise with adjustable guide rails and adjustable arm bracket to hold the cut-off piece, for burr-free finished cuts. Replaceable vise jaws allow the installation of profiled jaws for special applications.

CONTROL SYSTEMS

For a minimum of maintenance and service, the electric system is held at the necessary minimum, including main switch, overload switches and 24 Volt circuit to watch the air control system.
The automatic cycle of clamping and down-feed is completely air controlled, including the Emergency Stop button which locks the vise cylinder in any emergency situation, and with selective switch for permanent or stop & go motor drive. A control desk incorporates the manual actuators (Start / Stop / Emergency Stop), a cycle counter and an air coupling to install the air hose of the vise cylinder. Operating pressure for the air supply: 6 bar.

Motor wired 220 or 460volt, 3 phase 2 speeds 27/54rpm
Includes built in flood coolant system
Double hinged saftey guard with double air vise system
1-450mm HSS sawblade and 1- complete set of wrenches.
