PMI PANTHER BS-300A
The PMI Panther BS-300A fully automatic horizontal bandsaw with NC touchscreen control offers
high performance sawing capability where production, accuracy and ease of set up are of importance.
The saw is ideal for machine shops and metal service centers that cut a wide variety of materials up to
13” in diameter.
high performance sawing capability where production, accuracy and ease of set up are of importance.
The saw is ideal for machine shops and metal service centers that cut a wide variety of materials up to
13” in diameter.
Base price
Description
Standard Features & Equipment:
NC touchscreen control for setting length of cut
and number of cuts on multiple jobs
Power driven chip brush
Hydraulic feed rate & feed pressure adjustment
Hydraulic blade tension control
Multiple shuttle strokes
Idler wheel motion detector
Split front vise
Floating shuttle vise system
Out of material alarm
Automatic chip conveyor
Variable speed drive with inverter
Unique 2 way carriage vise jaw
Work light
Auto head-elevation and rapid approach
Full stroke cylinder for front and rear vise
Auto kerf loss compensation
Specifications
| Round | 13" | Bundle |
| Rectangle | 10" H x 13" W | 6 12/" H x 10" W |
| Square | 12" H x 12" W | |
| Blade Size | 12' 6" x 1 1/4" x .042" | |
| Blade Speeds | Variable 65 - 260 FPM | |
| Blade Motor | 5 HP | |
| Dimensions | 81" x 80" | |
| Gross Weight | 3,610 lbs. | |
| Hydraulic Motor | 1 HP | |
| Coolant Motor | 1/8 HP |
