STANDARD FEATURES

• Console Located on Front of Saw - All Function Control
• Touch Screen (Flat Panel Touch Control)
• 0-34" Stroke Bar-Feed System w/ Multiple Indexes
• Computer Controlled Feed System
• Material Jogging Feature
• 24" Solid Discharge Table
• Full Stroking Vises
• Powered Miter w/ Angle Readout
• Cut Watcher System
• Flat Carbide Blade Guides
• Adjustable Blade Speed
• Adjustable Clamping Force
• Adjustable Cutting Force
• Adjustable Feed Rate
• Powered Blade Tension
• Powered Guide Arm
• Chip Auger System
• Blade Chip Brush
• Out of Stock Indicator
• Broken Blade Indicator
• Safety Guards
• Lock Out - Tag Out System
• Flood Coolant System w/ Wash-Down Hose
• 220/440/3PH Electrical Motor Requirement

Capacity

• 20" x 30" W @ 90°
• 20" x 20" W @ 45° (Left Miter)
• 20" x 13" W @ 60° (Left Miter)
• Blade: 1-1/2" x 20'6" x .050"
• Motor: 10 HP
• Hydraulics: 5 HP
