STANDARD FEATURES

• Easy View Console - Semi-Automatic Control
• 18" Exit Support
• Hold Down Fixture
• Flat Carbide Blade Guides
• Push Button Blade Speed w/ LED Readout
• Adjustable Clamping Force
• Adjustable Cutting Force
• Adjustable Feed Rate
• Manual Blade Tension
• Manual Guide Arm Adjustment
• Blade Chip Brush
• Broken Blade Indicator
• Safety Guards
• Flood Coolant System w/ Wash-Down Hose
• 85 PSI, 4-6 CFM Minimum Air Requirement
• Equipped with Air Filter/Lubricator
• 220/440/3PH Electrical Motor Requirement

Capacity

• 16" x 22" W @ 90°
• 16" x 15" W @ 45°
• 16" x 7" W @ 60°
• 7" x 10" W @ 60° (Miter Only One Direction)
• Blade: 1-1/4" x 16'0" x .042"
• Motor: 7.5 HP
